Every callback eats margin, time, and customer trust. Most return visits tie back to spring selection, winding, or balance verification. Use this practical checklist to match torsion springs correctly, document your installation and leave each job dialed in.

1) Confirm the door

  • Door height and panels
    Measure true height. Note panel count and construction type to anticipate weight distribution.
  • Hardware and track type
    Standard lift, high lift, or low headroom. Verify drum part numbers before calculating turns.
  • Opener type and condition
    Belt, chain, or direct drive. Check force settings and travel limits after spring work.

2) Capture accurate weight

  • Best: Lift the door off the opener and place a scale under the center.
  • Alternate: Use manufacturer data and validate with a balance test.
    Record the number. Accurate weight is the foundation of correct springing.

3) Identify the existing springs

  • Inside diameter
    Most residential sets are 1.75 in or 2.00 in. Confirm by cone stamp or measurement.
  • Wire size
    Count 20 coils and measure the length. Convert to gauge with your shop chart.
  • Relaxed length
    Measure off tension, end to end. Note if your catalog excludes cone length.
  • Wind direction
    Right wind and left wind. Stock both. Pair correctly on the shaft.
  • Cycle rating
    Note current rating and consider an upgrade when usage is heavy.

Pro tip: If specs are uncertain or mixed, replace both springs as a matched pair. Avoid blending new and worn springs.

4) Choose the replacement springs

  • Match torque, not only size
    Use your calculator to hit the required IPPT for the measured door weight and drum.
  • Check clearance
    Verify spring outer diameter will clear at the planned shaft height.
  • Cycle strategy
    Offer two quotes: standard 10k cycle and an upgraded 20k plus. The small price delta often prevents future labor.

5) Inspect and prep the system

  • Cables and drums
    Replace frayed cables. Confirm drum model matches lift type.
  • Bearings and center bracket
    Spin bearings. Replace rough units. Confirm anchor bolts are solid.
  • Hinges and rollers
    Tighten fasteners, replace worn rollers, and lubricate moving points.

6) Install and wind with control

  • Mount springs with correct wind orientation.
  • Set cable drums with even tension and clean cable lay.
  • Wind in quarter turns to specification. Keep a firm grip on winding bars.
  • Tighten set screws to spec. Log the final turns per side.

7) Balance test sequence

  1. Half lift test
    Disconnect opener. Lift to mid travel. Door should hold with light hand force.
  2. Full travel
    Open fully. The door should not rise further or drop.
  3. Bottom seal contact
    Close to the floor. Ensure even seal compression without bounce.
  4. Fine tune
    Adjust in quarter turns to achieve neutral balance. Recheck cable tension and drum set screws.

8) Opener integration

  • Reconnect the opener and reset travel limits.
  • Reduce force settings if springs now carry the load correctly.
  • Run three full cycles and listen for rubbing or cable jump.

9) Document the job

  • Door height, width, and measured weight
  • Spring ID, wire size, relaxed length, wind, and cycle rating
  • Drum part number and final turns per spring
  • Balance test results and any hardware replaced

A simple photo of the installed springs, drums, and label on the box can save a future truck roll. Store these notes in your job system.

10) Customer communication

Explain that springs wear items with a rated cycle life. Offer a maintenance plan with lubrication and inspection every six to twelve months. Set expectations now to win future service calls while avoiding emergency returns.

Common causes of callbacks and quick fixes

  • Door creeps at half lift
    Recheck weight, turns, and drum spec. Confirm both cables have equal tension and proper wrap.
  • Opener strains or stalls
    Springs underwound or mis-sized. Return to neutral balance before changing opener force.
  • Uneven closing or daylight at one side
    Cable miswrap, drum set screw slip, or track out of plumb. Correct mechanical issues first, then revisit spring balance.
  • Noise after install
    Lack of lubrication at hinges and bearings. Apply the correct lubricant, not cleaner.
  • Bottom section bounce
    Too much stored energy or wrong drum for lift type. Reduce turns in small increments after confirming specs.

Stocking to prevent surprises

Carry a compact matrix that covers 80 percent of residential calls, then replenish fast movers weekly. Keep both winds and long cycle variants for your top three wire sizes. Label boxes on two faces with ID-wire-length-wind-cycle for quick grabs in the field.
