SGD Springs

Surewinder

Name: Surewinder
Brand: SGD Springs
SKU: sure-1
Price: 855.00 USD
Availability: InStock

Surewinder

Shipping calculated at checkout.

Estimated Delivery : 2-3 business days

In stock

Quantity

Texas proud company
Ready to ship
Secure checkout

Product Description

The industry-leading torsion spring winding tool, designed by aerospace engineers and field-proven for over a decade, ensures faster and safer winding and unwinding of springs.

Specifications

Designed for residential and light commercial applications
Wind springs up to 127 IPPT (8 turns) for a total of 1,020 in-lbs or 85
ft-lbs of torque. This is equivalent to .362" wire x 3.75" ID x 35" long
with 8 turns .
The Surewinder can wind a .362 x 3.75 ID X 35
in long spring 8 turns with a Milwaukee M18 FUEL 2804 Li-ion cordless
1/2" drill (7 turns in high gear, 1 turn in low gear) which is rated for
1,200 in-lbs of torque in drill (not hammer) mode. NO IMPACTS.
10 turns in under a minute with 1,000 RPM drill.
Needs 2.5 inches clearance from shaft to wall
Can be used on up to 4.5 inch spring diameters, 1 inch shaft diameters.
Can be wound at 2,500 RPM.
Weighs 7.5 lbs, dimensions: 21” long x 6” wide x 3.5” deep
Made from 304 Stainless steel and high temper bronze for wear resistance. Aerospace grade fasteners.

Health & Safety Benefits

Worm gear technology prevents the spring from back-driving the tool
Removes dangers inherent in winding bars
Lowers worker compensation claims and lost work time
Minimize fatigue and resulting safety incidents
Reduces rotator cuff injury

Cost Savings

Wind and unwind springs up to 10 times faster than winding bars
If you pay your techs $60K per year and your work comp rate is 4.5%,
insurance agents say you could get a 20% premium reduction and pay for
the tools for all techs in one year
Lowers worker compensation claims and lost work time
Increase revenue by completing more jobs in a week due to reduced fatigue
Warranty: our tools have been in the field with no problems for 10 years. One
year warranty for defects in workmanship and materials from date of
purchase from Surewinder LLC
